Skidsteer Laser Grader
  • View the main image of the Skidsteer Laser Grader
  • View the second image of the Skidsteer Laser Grader
  • View the third image of the Skidsteer Laser Grader

Skidsteer Laser Grader

  • Push-pull design for grading in forward or reverse
  • Pneumatic swivel wheels with tapered roller bearings on king pins, on oscillating front axle
  • Tapered roller bearings on axle oscillation pivot
  • Removable shims on main oscillation pivot to keep wear joint tight
  • Two 2-1/2" x 6" cylinders provide cross-slope operation
  • Reversible cutting edges
  • Universal laser mast mount
  • Levels consistently within 1/4" of target grade
  • Control valve included, does not include laser or grade control electronics
Part Number Description APPROX. WEIGHT
LBS.
SLG84Skidsteer Laser Grader1,610
HK90Optional 90" Hose Kit c/w Flat Faced Couplers
SHMKOptional Spring Hose Mount Kit
