10,000 LB Cap. - Heavy Duty Pallet Fork
- 2" x 6" Class III hook type solid fork lift tines
- 10,000 lbs capacity @ 24" L.C.
- C/w guard
- 50" wide carriage
- Sliding adjustable tines can be locked in any position
- OPTIONAL - Full back guard (Brick Guard)
| Part Number | Description | TINE LENGTH | APPROX. WEIGHT LBS. |
|---|---|---|---|
| HD10048 | Heavy Duty Pallet Fork c/w Guard - 48" Tines | 48" | 690 |
| HD10054 | Heavy Duty Pallet Fork c/w Guard - 54" Tines | 54" | 735 |
| HD10060 | Heavy Duty Pallet Fork c/w Guard - 60" Tines | 60" | 770 |
| HD10072 | Heavy Duty Pallet Fork c/w Guard - 72" Tines | 72" | 840 |
| HD100 | Carriage Only c/w Guard Less Tines | ||
| HD100BG | Optional - Full Back Guard Option (Brick Guard) |
