High Volume Skidsteer Bucket - REGULAR DUTY

High Volume Skidsteer Bucket - REGULAR DUTY

  • REGULAR DUTY
  • 3/16" material, ¼" end plates
  • ¾ X 4 bevelled cutting edge
  • Reinforced top lip
  • 34" deep, 31" high
  • Reinforced round back and end plates for strength, easy filling & clean out
  • Flat top acts as level indicator
  • Tapered end plates are self-cleaning and reduces material build-up
  • NOTE: Add 2" to Inside Width column to calculate outside width of bucket
Part Number Description INSIDE WIDTH
INCHES
STRUCK CAP.
CU. FT.
SAE HEAPED CAP.
CU. FT.
APPROX. WEIGHT
LBS.
SBHV6060" High Volume Skidsteer Bucket6020.825.5540
SBHV6666" High Volume Skidsteer Bucket6622.928.1570
SBHV7272" High Volume Skidsteer Bucket7225.030.8605
SBHV7878" High Volume Skidsteer Bucket7827.133.5650
SBHV8484" High Volume Skidsteer Bucket8429.136.1680
SBHV9696" High Volume Skidsteer Bucket9633.341.5760
SBHV108108" High Volume Skidsteer Bucket9637.546.8835
346CEBOptional 346CEB 3/4 X 6 Double Bevel Bolt On Cutting Edge c/w Bolts & Nuts
348CEBOptional 348CEB 3/4 X 8 Double Bevel Bolt On Cutting Edge c/w Bolts & Nuts
346CESBOptional 346CESB 3/4 X 6 Single Bevel Serrated Bolt On Cutting Edge c/w Bolts & Nuts
RTMBKOptional RTMBK Knock On Ripper Teeth c/w Weld On Adapter & Flex Pin
