Compact Utility Bucket - Skidsteer

Compact Utility Bucket - Skidsteer

  • ⅛" material, 3/16" end plates
  • ½ X 4 bevelled cutting edge
  • 21" deep, 18" high
  • 65° slope on back of bucket
  • Reinforced round back and end plates for strength, easy filling & clean out
  • Flat top acts as level indicator
  • Drilled for standard bolt on cutting edge
Part Number Description INSIDE WIDTH
INCHES
STRUCK CAP.
CU. FT.
SAE HEAPED CAP.
CU. FT.
APPROX. WEIGHT
LBS.
SBC4242" Skidsteer Compact Utility Bucket424.96.1230
SBC4848" Skidsteer Compact Utility Bucket485.77.2245
SBC5454" Skidsteer Compact Utility Bucket546.48.1260
SBC6060" Skidsteer Compact Utility Bucket607.19.0275
SBC6666" Skidsteer Compact Utility Bucket667.810.0285
SBC7272" Skidsteer Compact Utility Bucket728.510.9310
